[Rhodes22-list] Chain plate

Slim Chance slimsails at gmail.com
Fri Jan 27 17:45:14 EST 2012


As Rob said, the chain plates originally go through the cabin roof and then
bent at a 90 degree angle and affix to the cabin roof inboard of the slot.
My fix kept the chain plate straight and affix to the cabin side and
through-bolted. (This is my second attempt to attach pix. First one got
rejected because it was too big. I'll try sending then one at a time.)

On Fri, Jan 27, 2012 at 4:17 PM, Slim Chance <slimsails at gmail.com> wrote:

> As Rob said, the chain plates originally go through the cabin roof and
> then bent at a 90 degree angle and affix to the cabin roof inboard of the
> slot. My fix kept the chain plate straight and affix to the cabin side and
> through-bolted. (Let's see if I remember how to attach photos...)
>
> On Fri, Jan 27, 2012 at 9:06 AM, Goodness <spreadgoodnews at gmail.com>wrote:
>
>> Thanks for the input and visual on how the chainplate is attached.  My
>> boat has a history of a tree falling on it while the mast was down for
>> trailering. The tree may have pushed that tang down. Bent the mast, busted
>> the hatch,   Cracked the glass around a winch otherwise no other apparent
>> damage and should all be easy repairs.  The nice thing about 6 shrouds is
>> that the rig stays up if one comes out or breaks.
>>
>>
>>
>> On Jan 27, 2012, at 9:36 AM, "Lowe, Rob" <rlowe at vt.edu> wrote:
>>
>> > Hank,
>> > Yes, I do!  I don't think chalking will do a bit of good!  I've always
>> said my spelling skills are on par with my sailing skills.
>> >
>> >
>> > And I agree with not using 5200.  I think we decided the 4300 was a
>> more flexible and removable product. - rob
>> >
>> >
>> > -----Original Message-----
>> > From: rhodes22-list-bounces at rhodes22.org [mailto:
>> rhodes22-list-bounces at rhodes22.org] On Behalf Of Hank
>> > Sent: Friday, January 27, 2012 9:33 AM
>> > To: The Rhodes 22 Email List
>> > Subject: Re: [Rhodes22-list] Chain plate
>> >
>> > Rob,
>> >
>> > You keep saying chalk.  Do you mean caulk?
>> >
>> > Hank
>> > On Jan 27, 2012 9:20 AM, "Lowe, Rob" <rlowe at vt.edu> wrote:
>> >
>> >> Goodnews,
>> >> There have been multiple posts over the years on loose stays.  Both
>> >> Slim and I have had stays that have pulled out the chain plates and
>> >> needed to be repaired.  I've got those saved somewhere, not finding
>> them at the moment.
>> >> The chai nplates that enter the cabin roof are bent and are screwed
>> >> to the plywood that makes up the cabin top.  You are correct, the
>> >> cabin liner prevents access to them, we had to have access holes cut
>> >> in the liner to gain access.  Some chalk may be a short term fix for
>> >> now.  If you chalk, be aware that once you load that stay the chalk
>> >> probably pull out.  Better to load the stay, then chalk so the chalk
>> >> gets pulled into the cabin top.  My old boat was a 76 and did have
>> >> some plywood rot.  There are whole posts on epoxy repairs.  Might try
>> >> to search achieves. - rob
>> >>
>> >> -----Original Message-----
>> >> From: rhodes22-list-bounces at rhodes22.org [mailto:
>> >> rhodes22-list-bounces at rhodes22.org] On Behalf Of Goodness
>> >> Sent: Friday, January 27, 2012 7:19 AM
>> >> To: The Rhodes 22 Email List
>> >> Subject: Re: [Rhodes22-list] Chain plate
>> >>
>> >> Thanks.  It looks like some caulk came out of the small joint where
>> >> the chain plate is loose from the cover plate.  If the chainplates are
>> >> toggles then wiggling would occur.  I will just squirt in some 3m 5200
>> >> and call it a day.
>> >> With regards to the electric motor.  I was looking at the cockpit
>> >> drain through hull.  That looks like a perfect mounting hole for those
>> >> electric drives designed to be through hull mounted.  It would be a
>> >> simple matter to re-route the cockpit drain.
>> >> A hybrid electric drive, small diesel generator in aft compartment and
>> >> agm batteries( mounted behind the v berth floatation foam) would be a
>> >> real possibility!
>> >>
>> >>
>> >> On Jan 26, 2012, at 10:19 PM, John Shulick <jsbudda at verizon.net>
>> wrote:
>> >>
>> >>>
>> >>> Goodnews,
>> >>>
>> >>> One of mine is like that too. sailing with it like that for 4yrs now
>> >>> so far no problem.
>> >>> Note: now that I've opened my big mouth about it I probably be
>> >>> posting around June or so on how to fix it. Chance of failure
>> >>> increases in exponential proportion to statements about something not
>> failing.
>> >>>
>> >>> Like the Inboard electric drive Idea BTW. Keel stepping the carbon
>> >>> mast would hinder moving around in the cabin I prefer stays. (also
>> >>> could use the baby stays to make it a bendy mast)
>> >>>
>> >>> John S
>> >>>
>> >>>
>> >>> Spreadgoodnews wrote:
>> >>>>
>> >>>>
>> >>>> Ok, i need help on this one.  While going over the boat i found one
>> >>>> of the forward chainplates is loose when you push down but strong
>> >>>> and
>> >> firm when
>> >>>> you pull up.  It moves only 1/4" or less.    Since i am unfamiliar
>> with
>> >>>> the chainplate and you cant see it for the liner i need some advice.
>> >>>>
>> >>>>
>> >>>> __________________________________________________
>> >>>> To subscribe/unsubscribe go to
>> >>>> http://www.rhodes22.org/mailman/listinfo/rhodes22-list
>> >>>>
>> >>>> For the list Charter and help with using the mailing list and
>> >>>> archives go to http://www.rhodes22.org/list
>> >>>> __________________________________________________
>> >>>>
>> >>>>
>> >>>
>> >>> --
>> >>> View this message in context:
>> >>> http://old.nabble.com/Chain-plate-tp33211855p33211910.html
>> >>> Sent from the Rhodes 22 mailing list archive at Nabble.com.
>> >>>
>> >>> __________________________________________________
>> >>> To subscribe/unsubscribe go to
>> >>> http://www.rhodes22.org/mailman/listinfo/rhodes22-list
>> >>>
>> >>> For the list Charter and help with using the mailing list and
>> >>> archives go to http://www.rhodes22.org/list
>> >>> __________________________________________________
>> >>
>> >> __________________________________________________
>> >> To subscribe/unsubscribe go to
>> >> http://www.rhodes22.org/mailman/listinfo/rhodes22-list
>> >>
>> >> For the list Charter and help with using the mailing list and archives
>> >> go to
>> >> http://www.rhodes22.org/list__________________________________________
>> >> ________
>> >>
>> >> __________________________________________________
>> >> To subscribe/unsubscribe go to
>> >> http://www.rhodes22.org/mailman/listinfo/rhodes22-list
>> >>
>> >> For the list Charter and help with using the mailing list and archives
>> >> go to http://www.rhodes22.org/list
>> >> __________________________________________________
>> >>
>> > __________________________________________________
>> > To subscribe/unsubscribe go to
>> http://www.rhodes22.org/mailman/listinfo/rhodes22-list
>> >
>> > For the list Charter and help with using the mailing list and archives
>> go to http://www.rhodes22.org/list__________________________________________________
>> >
>> > __________________________________________________
>> > To subscribe/unsubscribe go to
>> http://www.rhodes22.org/mailman/listinfo/rhodes22-list
>> >
>> > For the list Charter and help with using the mailing list and archives
>> go to http://www.rhodes22.org/list
>> > __________________________________________________
>>
>> __________________________________________________
>> To subscribe/unsubscribe go to
>> http://www.rhodes22.org/mailman/listinfo/rhodes22-list
>>
>> For the list Charter and help with using the mailing list and archives go
>> to http://www.rhodes22.org/list
>> __________________________________________________
>>
>
>
